Specifications

• PRICING

  add remove
  • Price:
    Standard
  • MSRP:
    26600
  • MSRP + Destination:
    26600
  • Currency:
    US Dollars
  • Warranty (Months):
    24
  • Warranty (Condition):
    Limited
• ENGINE

  add remove
  • Engine:
    Standard
  • Engine Brand Name:
    S&S
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valve Configuration:
    OHV - Pushrod
  • Bore (mm):
    104.8
  • Bore (in):
    4.13
  • Stroke (mm):
    111.1
  • Stroke (in):
    4.38
  • Displacement (cc):
    1916
  • Displacement (ci):
    117
  • Compression Ratio:
    9.6:1
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Carburetion:
    Standard
  • Fuel Injector:
    No
  • Carburetor:
    Yes
  • Carburetion Type:
    Carburetor
  • Parental Controls:
    Not Available
  • Other Engine:
    Optional
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Belt
  • Primary Drive (Engine / Transmission):
    Chain
  • Heel Toe Shifter:
    Standard
  • Adjustable Throttle:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (in):
    103
  • Length (mm):
    2616.2
  • Wheelbase (in):
    77.5
  • Wheelbase (mm):
    1968.5
  • Ground Clearance (in):
    4
  • Ground Clearance (mm):
    101.6
  • Weight:
    Standard
  • Dry Weight (lbs):
    653
  • Dry Weight (kg):
    296.2
  • GVWR (lbs):
    1085
  • GVWR (kgs):
    492.2
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    4.6
  • Fuel Capacity (l):
    17.4
  • Fuel Capacity Reserve (gal):
    0.7
  • Fuel Capacity Reserve (l):
    2.6
  • Performance:
    Standard
  • Engine Displacement to Weight (cc):
    2.93
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Steel
  • Floor Boards:
    Not Available
  • Foot Pegs:
    Standard
  • Foot Peg Location:
    Driver
  • Hand Grips:
    Standard
  • Handlebars:
    Standard
  • Handlebar Pads:
    Not Available
  • Exterior Guards:
    Standard
  • Belt Guard:
    Yes
  • Brush Guard:
    No
  • Chain Guard:
    No
  • Engine Case Guard:
    No
  • Exhaust Guard:
    No
  • Fork Guards:
    No
  • Hand Guards:
    No
  • Heel Guards:
    No
  • Light Guard:
    No
  • Saddle Bag Guard:
    No
  • Tank Guard:
    No
  • Exterior Covers:
    Standard
  • Side Cover:
    Yes
  • Front Fender:
    Standard
  • Front Fender Trim:
    Not Available
  • Front Fender Rail:
    Not Available
  • Rear Fender:
    Standard
  • Rear Fender Trim:
    Not Available
  • Rear Fender Rail:
    Not Available
  • Top Crown:
    Standard
  • Tank Divider:
    Not Available
  • Stand:
    Standard
  • Stand Type:
    Kick
  • Upper Fairing:
    Not Available
  • Lower Fairing:
    Not Available
  • Spoiler:
    Not Available
  • Skid Plate:
    Not Available
  • Wind Deflector:
    Not Available
  • License Plate:
    Standard
  • Fuel Tank Cover:
    No
  • Other Exterior:
    Optional
• STEERING

  add remove
  • Steering:
    Standard
  • Steering Control:
    Handlebar
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.6
  • Front Suspension Size (mm):
    41
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Rigid
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Chromed:
    Yes
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Front Tire Aspect Ratio:
    70
  • Front Tire Speed Rating:
    MH
  • Front Wheel Diameter:
    21
  • Rear Tire Width:
    300
  • Rear Tire Aspect Ratio:
    35
  • Rear Wheel Diameter:
    18
  • Front Tire (Full Spec):
    MH120/70-21
  • Rear Tire (Full Spec):
    300/35 R18
  • Spare Tire:
    Not Available
  • Front Tire Width:
    120
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Disc
  • Rear Brake Type:
    Disc
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
• SEATS

  add remove
  • Seat:
    Standard
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Leather
  • Seat Specifications:
    Standard
  • Seat Height (in):
    24.3
  • Seat Height (mm):
    617.2
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Optional
  • Seat Tail Cover:
    Not Available
  • Seat Rail:
    Not Available
  • Grab Rail or Strap:
    Not Available
  • Heated Seat:
    Not Available
  • Sidecar:
    Not Available
• GLASS

  add remove
  • Folding:
    Yes
  • Rearview Mirrors:
    Standard
  • Windshield:
    Optional
  • Sidecar Windshield:
    Not Available
  • Windshield Wipers:
    Not Available
  • Other Glass:
    Optional
• INSTRUMENTATION

  add remove
  • Digital Instrumentation:
    Standard
  • Clock:
    Not Available
  • Speedometer:
    Standard
  • Tachometer:
    Standard
  • Trip Odometer:
    Standard
  • Compass:
    Not Available
  • Navigation System:
    Not Available
  • GPS:
    Not Available
  • Lap Timer:
    Not Available
  • Fuel Level Warning:
    Not Available
  • Oil Pressure Gauge:
    Not Available
  • Temperature Warning:
    Not Available
  • Shift Light:
    Not Available
  • Service Reminder:
    Not Available
  • Multi-Lingual Instrumentation:
    Not Available
• STORAGE

  add remove
  • Hard Side Cases:
    Not Available
  • Saddle Bag(s):
    Not Available
  • Side Storage Mount:
    Not Available
  • Fork Bag:
    Optional
  • Tail Bag:
    Optional
  • Tank Bag:
    Not Available
  • Leather Storage:
    Optional
  • Underseat Storage:
    Not Available
  • Lockable Storage:
    Not Available
  • Front Rack:
    Not Available
  • Front Rack Storage:
    Not Available
  • Rear Rack:
    Optional
  • Rear Rack Storage:
    Optional
  • Side Rack:
    Not Available
  • Side Rack Storage:
    Not Available
  • Bag Liners:
    Not Available
  • Cupholder:
    Not Available
  • Storage Cover:
    Optional
  • Sidecar Storage Cover:
    Not Available
  • Map Holder:
    Not Available
  • Helmet Locks:
    Not Available
  • Helmet Storage:
    Not Available
  • Sidecar Front Rack:
    Not Available
  • Sidecar Rear Rack:
    Not Available
  • Sidecar Fender Rack:
    Not Available
  • Sidecar Trunk:
    Not Available
  • Glove Box / Dash Storage:
    Not Available
• LIGHTS

  add remove
  • Headlight(s):
    Standard
  • Type:
    Halogen
  • Halogen Headlight(s):
    Standard
  • Adjustable Headlights:
    Not Available
  • Fog Lights:
    Not Available
  • Headlight Mounts:
    Standard
  • Headlight Mounting Bar:
    Not Available
  • Headlight Visor:
    Not Available
  • Turn Signal Visor:
    Not Available
  • Passing Lamps:
    Not Available
  • Passing Lamp Visors:
    Not Available
• CONVENIENCE

  add remove
  • Engine Immobilizer:
    Not Available
  • Heated Hand Grips:
    Not Available
  • Keyless Ignition:
    Not Available
  • Power Outlet:
    Not Available
  • Cruise Control:
    Not Available
  • Adjustable Handlebars:
    Not Available
  • Adjustable Levers:
    Not Available
  • Alarm System:
    Not Available
  • Handlebar Lock:
    Standard
  • First Aid Kit:
    Not Available
• AUDIO & COMMUNICATION

  add remove
  • Radio:
    Not Available
  • Speakers:
    Not Available
  • Cassette Player:
    Not Available
  • CD Player:
    Not Available
  • CB Radio:
    Not Available
  • Intercom:
    Not Available
  • Headset:
    Not Available
• MOUNTS

  add remove
  • Saddle Bag Mounts:
    Not Available
  • Side Case Mount:
    Not Available
  • Tool Bag Mount:
    Optional
  • Windshield Mounts:
    Optional
  • Other Mounts:
    Optional
• PAINT & FINISH

  add remove
  • Paint:
    Standard
  • Decal Kit:
    Not Available
  • Other Paint & Finish:
    Optional
• SPECIAL PACKAGE

  add remove
  • Special Package:
    Not Available
• COMMENTS

  add remove
  • Comment:
    Optional
